Spring Loaded Magnetic Flange to ½”Gas

Achieving uniform, shadow-free sunken drainboards and recessed drainer trays on CNC router machines can be challenging without built-in dynamic pressure detection. Varied slab thickness, slight bed unlevelness, or minor tool deflection often lead to uneven milling depth, high spindle load, and premature burning of expensive diamond tooling.

The Spring Loaded Recess Adaptor solves this by introducing mechanical float into your spindle setup. Bridging a standard 1/2″ Gas male thread to a rapid magnetic fitting, this adaptor acts as an active shock absorber during recess milling operations. By continuously dampening downward forces and absorbing micro-height fluctuations across the slab face, it maintains sufficient pressure for optimal results without risking tool chatter, friction heat, or diamond glazing.

Key Features & Technical Specifications

• 1/2″ Gas to Magnetic Fitting: Features a standard 1/2″ Gas thread for immediate integration with standard CNC spindle cones, pairing with a magnetic tool coupling for fast, secure, and accurate tool changing.

• Mechanical Pressure Compensation: Replicates dynamic surface-tracking functionality on CNC machines without integrated pressure sensors, maintaining consistent downward force over unlevel slabs.

• Eliminating Tool Glazing & Burning: Absorbs peak resistance during heavy step-down passes, preventing diamond tooling from overheating, binding, or burning the stone substrate.
