Recess Magnetic Flange to Bore 35×36

Precision sunken drainboards and recessed drainer trays demand rigid tool retention to eliminate micro-vibration, chatter marks, and inconsistent milling depths. The Recessed Drainer Magnetic Holder delivers a secure, zero-play connection between your CNC tool holder and magnetic recess tooling.

Built around a robust 35mm bore specification, this heavy-duty adapter features a 36mm primary body length complemented by an extended 10mm guidance collar (36mm + 10mm). This additional engagement depth increases structural rigidity across the spindle connection, absorbing heavy side loads during aggressive material removal. Coupled with a high-flux internal magnetic coupling, it enables effortless, repeatable tool swaps without sacrificing the mechanical locking force required for smooth, burn-free recessing across natural and engineered stone.

Technical Features

• Precision 35mm Internal Bore: Machined to tight engineering tolerances for a seamless fit onto standard 35mm CNC tool holders, eliminating axial runout and unwanted movement.

• Extended 36mm + 10mm Profile: Designed with a 36mm main body and an additional 10mm alignment section to maximize contact surface area, providing superior resistance against lateral deflection during deep milling passes.

• Industrial High-Flux Magnetic Core: Houses a high-retention magnet that firmly locks magnetic recess tools into place, ensuring complete operational safety while facilitating rapid manual tool changes.

• Vibration-Dampening Construction: High-mass steel body absorbs mechanical chatter, protecting both the CNC spindle bearings and the diamond matrix on the milling tool.

• Slurry-Resistant Sealing: Built to withstand constant exposure to abrasive stone slurry and high-pressure internal or external cooling water.

Tool Application & Compatibility

• Primary Application: Securing magnetic recess drain tooling for sunken drainboard, drainer groove, and hob recess milling on automated CNC machinery.

• Holder Compatibility: Mounts directly onto standard 35mm bore CNC tool holders.

• Tool Interface: Accepts standard magnetic recess drain milling heads and profiling tools.

• Material Suitability: Suitable for high-load milling across all stone types, including granite, quartz, marble, limestone, and ceramic substrates.
